AD-NGA Automatic sliding door

AUTOMATIC DOORS

COMPARE ADIS ADVANTAGES

ADIS is australian owned and australian manufactured.
•NATA teted to comply with AS 5007, 1 million cycles performance.
•Slim line modern design only 132 mm in overall track height.
•Compact modular design of motor drive system.
•Latest digital microprocessor controller to gain more exact control of the door operator,Provision to interface with building security systems.
•Over engineered to take total door weights of up to 300Kg (max single leaf door weightof 150 Kg).
• The main transom housing is hard coated anodized to give smooth operation of the exclusive dual track system.
•No exposed wiring due to concealed wiring system.
•Built in UPS (Uninterrupted Power Supply) can allow doors to continue to operate under apower failure when doors are locked. This is a standard feature in ADIS NGA operator not anextra.
•Improved multiple safety features to ensure maximum user safety.
•High security electric motor locking.
•Zone activation sensor system that uses latest presence detection technology to improveoverall safety.
•Unique interlocking cover pelmet which prevents any chances of pelmet cover dislodgingfrom the main track system. An added safety feature.

BACK UP SERVICE
Fully qualified technicians to meet our high standard of company service.
•A complete 24 hour, 7 days a week, ongoing preventive maintenance service.
•Extensive nationwide service network via our 1800 number.

The Company

ADIS AUTOMATIC DOORS is a fully Australian owned and operated company.
The name ADIS simply means, Automatic Door Installation Services. The company has over 35 years of experience in the Automatic Doors Industry.
ADIS philosophy is provide a high quality product at a competitive price backed by the highest standard of  back up service to achieve total customer satisfaction. The introduction of the Next Generation Series of Automatic Door operators is a major advancement in automatic doors technology in the Australian and global automatic door markets. This series includes the most advanced features available in the world.
ADIS research and design team have developed the NG series of door equipment to ensure maximum performance, durability and reliability, plus compliance with the Australian Standard AS 5007-2007, tested by a independent NATA test laboratory for 1 million cycles under all terrain categories.
ADIS Automatic Doors have been successful in achieving the AUSTRALIAN DESIGN AWARD for excellence in product design & excellence in product efficiency.
Advanced Technology
ADIS utilizes the latest in digital microprocessor technology, giving the control unit multiple programmable modes including: – provision to interface with builidng security system, monitoring the doors position and locks status, built-in UPS. The microprocessor operating parameters can be adjusted to accommodate various climatic conditions and specific site requirements in relation to speed, braking etc. Safety is a priority: The ADIS microprocessor will automatically reverse operation while the door is closing, should the doors be obstructed. Photo electric or active infrared safety sensors are recommended to focus across the doorway to halt and open the doors immediately upon the sensor detecting an obstruction.

Mode Switch Control
The automatic door is controlled by a 6 position digital key pad with: Lock, Auto, Exit, Hold Open, Climate and Off Modes

Pelmet Hinge
The ADIS pelmet design features a unique interlocking hinge to provide secure closure and maximum cover even when mounted hard up against the ceiling.

High Security Locking
The Next Generation Series operators utilizes a purpose built motor which includes an electric locking system to ensure that the doors can be securely fixed in any position. This method of locking ensures the highest level of
security & comes with battery backup supply
